Kirpekar Engineering seek for higher technological development from a global point of view and introduction of more sophisticated machines to the markets. Obtaining high quality finished products, selection of the most suited forming machine and forming roll is indispensable.
We are not just a simple roll forming machine manufacturer. We design and manufacture the most suited forming roll, machine motion control and even provide mass production know-how of the finished products. This way, we can reply to customers' demands at a very high level.
We are the only Indian company to have manufactured and supplied turnkey panel radiator production lines in India and overseas.
We are the only Indian company to have an in-house tool design and manufacturing capability. This ensures strict quality control for all the critical processes like machining, heat treatment, assembly and testing after assembly
|Specifications||Model- KRFM- 520||Model- KRFM- 375|
|Maximum length of panel||3500 mm||2500 mm|
|Minimum length of panel||600 mm||400 mm|
|Thickness of assembled panel (flange to flange)||24 mm||24|
|Cold rolled steel thickness||Min 1.0 – Max 1.2 mm||Min 1.0 – Max 1.2 mm|
|Cold rolled steel width||520 (525) mm, 230 (235), 380 (385)||375 (380) mm, 300 (305) mm offset, 230 (235) mm|
|Voltage||3 Phase 415V AC.||3 Phase 415V AC.|
|Hydraulic Power Pack||15HP (approx.)||10HP (approx.)|
|Decoiler||3 ton Capacity||1 ton capacity|
|Manual Expansion type||Manual Expansion type|
|Suitable For Coil ID 450MM-500MM||Suitable For Coil ID 450MM-500MM|
|Automatic De coiling||Manual De coiling|
|Hydraulic Press||100 Ton||80 Ton|
|Radiator Details||Available in 21 flutes and 24 flutes||15 flutes for 375 12 flutes for 300 9 flutes for 230|
|Spot welding flutes||6 for 21 flute design and 5 for 24 flute design||4 flutes for 375 3 flutes for 300 2 flutes for 230|
|Spot welding flute depth||4.5 mm ( average )||4.5 mm ( average )|
|Sub Flutes depth||1.2 mm ( average )||1.2 mm ( average )|
|Other Additional Features||130 mm offset die set||NA|
|Offered optionally||180 mm offset die set||NA|
|Die set with collar||NA|
